Manual control of built-in sunshade louver insulating glass

The built-in louver insulating glass is a new type of energy-saving glass product, which is used to install the louver in the insulating glass, giving consideration to both thermal insulation and sunshade performance.

The magnetic block operating handle is used to control the closing device and lifting device to operate the lifting and turning of the shutter in the insulating glass. The light and radiant heat entering the room can be controlled by adjusting the angle of the shutter to meet the needs of heat insulation and indoor lighting. Compared with other traditional sunshade products, the built-in louver insulating glass has more excellent properties such as thermal insulation, sunshade and daylighting, sound insulation and environmental protection, safety and reliability, dust-proof privacy, etc.

Product Features and Benefits

  • Light Adjusting

    High tech magnetic induction drive system can adjust the angle of the louver at will to make it fully transparent, semi transparent or shading.

  • Soundproof

    Magnetic control built-in louver insulating glass can reduce indoor noise up to 36 dB, ensuring perfect noise reduction and sound insulation effect.

  • Beauty

    The integrated design of the built-in louver insulating glass is not limited by the size of the hole, creating a personalized and private space, giving a new visual enjoyment. The shutter needs no cleaning, and has the advantages of dust prevention, oil smoke prevention and pollution prevention.

  • Energy Conservation

    It is estimated that when the shutter is closed, the energy saving effect can reach 40%. In summer, adjusting the shutter to the closed state can block the direct sunlight, block the convection of cold and hot air, and greatly reduce the energy consumption of indoor air conditioning. In winter, lift the shutter to allow direct sunlight, fully absorb heat energy, and with the barrier of the hollow layer, the indoor warm keeping temperature will increase in large days, so as to achieve energy-saving effect.

  • Safety

    Traditional sunshade products are mostly flammable. In case of fire, curtains made of cloth yarn and chemical fiber release a lot of toxic smoke when burning, causing asphyxiation and casualties of indoor personnel. The built-in louver insulating glass is not only resistant to open fire, but also will not release smoke in a fire. The double-layer tempered glass and the built-in aluminum magnesium louver also have the function of preventing the spread of fire, which is a safe and reliable fire protection product.

  • Maintenance Free

    It is clean and tidy, without curtains, easy to clean and disinfect, free of dust mites. During the production and use process, the sealed environment ensures that the shutter is not polluted and clean, and avoids tedious cleaning work.

Product control
